| Item | Description |
|---|---|
| Type | 70% Recirculatory & 10% Fresh Air |
| Floor Hatch / Wall Mounted | |
| Moc | SS-304/SS-316 /Customized |
| Flow | Vertical Laminar |
| Velocity at Nozzel | 0.45+/-0.05 MPS |
| Air Cleanliness | ISO Class – 5 |
| Surface Finish | Hairline Finish (Coved Cornners) / Customized |
| Motor & Blower | Statically & Dynamically Balanced Motor Blower |
| Hepa Filter | Hepa Filters Which Conforms to H13/H14 with Efficiency of 99.997% Down to 0.3 Micron |
| Pre Filter | Magnus Make Pre Filter Which Conforms to G4 Grade With Efficiency of 95% Down to 5 Micron |
| Handle | Round – Latch Type |
| Door | SS – 304 Double Walled Doors With Double Glazed View Panel |
| Door Orientation | Door Orientation Can be Customized |
| Door Interlocking | Electro Magnetic Interlocking / Mechanical Interlocking to Ensure Only One Door Opens at a Time |
| Door Handle | Round – Latch Type |
| Indicators | Indicator & Buzzer is Provided for Door Interlocking Signal |
| Return Grills | SS Return Air Grills |
| Lights/Switches | LED Lights & on/off Switches for Blower & Lights |
| Magnehelic Gauge | Dwyer/Equivalent Make Magnehelic Differntial Pressure Gauge Across Supply Hepa Filter and Across Pre Filter |
| DOP Port | DOP Test Port for Upstream of Hepa Filter |
| Vibration Level | Minimum |
| Power Supply | 220-230V AC / Single Phase / 50Hz |
